Model

A

(mm)

B

(mm)

C

(mm)

D

(mm)

E

(mm)

F

(mm)

Drain

FR-HE-45

302

149

151

Φ89

38

1＂

3/4＂

FR-HE-70

403

149

249

Φ89

38

1＂

3/4＂

FR-HE-130

490

149

300

Φ89

38

1-1/2＂

3/4＂

FR-HE-180

442

165

276

Φ105

40

1-1/2＂

1＂

FR-HE-250

571

165

405

Φ105

40

1-1/2＂

1＂

FR-HE-300

700

165

534

Φ105

40

1-1/2＂

1＂

FR-HE-500

1166

165

1000

Φ105

57

2＂

1＂

FR-HE-1000

968

204

764

Φ133

57

2＂

2＂
