- Features
| Material | SUS304, SUS316L |
| Max working pressure | 100Psi |
| Surface | Sandblast external surface |
Standard specifications
| Model | A (mm) |
B (mm) |
C (mm) |
F (mm) |
In/Out | Vent |
| 0.3M3 | Φ550 | 1220 | 18300 | 250 | 3/4＂ | 3/4＂ |
| 0.5M3 | Φ700 | 1220 | 1910 | 250 | 3/4＂ | 3/4＂ |
| 1M3 | Φ1000 | 1220 | 2110 | 300 | 1＂ | 3/4＂ |
| 2M3 | Φ1300 | 1500 | 2540 | 300 | 1＂ | 3/4＂ |
| 3M3 | Φ1600 | 1500 | 2690 | 300 | 1-1/2＂ | 3/4＂ |
| 4M3 | Φ1600 | 2000 | 3190 | 300 | 1-1/2＂ | 3/4＂ |
| 5M3 | Φ1800 | 2000 | 3290 | 300 | 1-1/2＂ | 3/4＂ |
| 6M3 | Φ1900 | 2000 | 3390 | 350 | 1-1/2＂ | 3/4＂ |
8M3 |
Φ2000 | 2500 | 3940 | 350 | 2＂ | 3/4＂ |
| 10M3 | Φ2200 | 2400 | 3940 | 350 | 2＂ | 3/4＂ |
